IG.100411

DJI Remote Monitor Expansion Plate

Sold out

Say goodbye to this product, it's sold out and we are no longer stocking it!
However, we'll keep this page up for your reference needs.

Please see your local DJI dealer, or check the DJI Store to purchase this part.

——————————

The DJI Remote Monitor Expansion Plate mounts to the back of the DJI High-Bright Remote Monitor.

It outputs both SDI and HDMI signals, and supports 6-Pin Lemo DC-IN (6.8V to 17.6V).

Our TB50 Battery Plate and TB51 Battery Plate work in tandem with this accessory for the ultimate Transmission pro workflow!

DJI Transmission is a game changer in terms of long range and low price point, but that comes at the cost of some latency and fan noise.

Keep in mind, from the TX to the DJI High-Bright Remote Monitor, latency is 68-125ms (frame rate depending).

When using the DJI Remote Monitor Expansion Plate, there's an additional 50-80ms (118-205ms total) when outputting vision from the SDI-OUT to an external monitor.

IN THE BOX
DJI Remote Monitor Expansion Plate
Four M2.5-9mm screws
2mm Ball-End Hex Key

WEIGHT
3.49oz / 99g

DIMENSIONS
3.5 x 1.25 x 1.02” / 89 x 32 x 26mm

DJI Remote Monitor Expansion Plate
